Category Archives: Linux

31Dec/16

Configure SSH Key based authentication from Linux and Windows system

Secure Shell (SSH)

Secure Shell (SSH) is a cryptographic network protocol for operating network services securely over an unsecured network. When working with a Linux server, chances are, you will spend most of your time in a terminal session connected to your server through SSH. There are different ways to login into the server using ssh and here I am discussing about the ssh key based authentication. Continue reading

26Aug/16

RAID and its different types

RAID is short for Redundant Array of Independent Disks

RAID is a technology that is used to increase the performance and/or reliability of data storage. It combines multiple physical disk drive components into a single logical unit.  Data in RAID is distributed across the drives in one of several ways, referred to as RAID levels, depending on the required level of redundancy and performance. The different schemas, or data distribution layouts, are named by the word RAID followed by a number

Different RAID Levels

  • RAID 0 – striping
  • RAID 1 – mirroring
  • RAID 5 – striping with parity
  • RAID 6 – striping with double parity
  • RAID 10 – combining mirroring and striping

Note

In all the diagrams mentioned below:
      A, B, C, D, E,F,G and H – represents blocks
      p1, p2,p3 and p4 represents parity

RAID LEVEL 0

RAID 0 divides a set of data among multiple hard drives, usually two drives.This configuration has striping but no redundancy of data. It offers the best performance but no fault-tolerance.If one drive fails then all data in the array is lost.

Raid level 0

Advantages

  • RAID 0 offers great performance, both in read and write operations. There is no overhead caused by parity controls.
  • All storage capacity is used, there is no overhead.
  • The technology is easy to implement.

Disadvantages

  • RAID 0 is not fault-tolerant. If one drive fails, all data in the RAID 0 array are lost. It should not be used for mission-critical systems.

Ideal Use

  • RAID 0 is ideal for non-critical storage of data
  • Minimum 2 disks
  • Excellent performance

RAID LEVEL 1

RAID 1 stores an exact copy of your data on two or more drives. This makes your data much more secure; if one drive in the system fails, your data can simply be retrieved from any other drive in the system. This is known as data redundancy.

RAID 1

Advantages

  • RAID 1 offers excellent read speed and a write-speed that is comparable to that of a single drive
  • In case a drive fails, data do not have to be rebuild, they just have to be copied to the replacement drive.
  • RAID 1 is a very simple technology.

Disadvantages

  • The main disadvantage is that the effective storage capacity is only half of the total drive capacity because all data get written twice.
  • Software RAID 1 solutions do not always allow a hot swap of a failed drive. That means the failed drive can only be replaced after powering down the computer it is attached to. For servers that are used simultaneously by many people, this may not be acceptable. Such systems typically use hardware controllers that do support hot swapping.

Ideal Use

  •  It is  suitable for small servers in which only two data drives will be used
  • Minimum 2 disks
  • Excellent redundancy

RAID LEVEL 5

Level 5 is one of the most popular configuration of RAID and is the most common secure RAID level. It requires at least 3 drives but can work with up to 16. Data blocks are striped across the drives and on one drive a parity checksum of all the block data is written. The parity data are not written to a fixed drive, they are spread across all drives.

RAID 5

Advantages

  • Read data transactions are very fast while write data transactions are somewhat slower.
  • If a drive fails, you still have access to all data, even while the failed drive is being replaced and the storage controller rebuilds the data on the new drive.

Disadvantages

  • Drive failures have an effect on throughput, although this is still acceptable.
  • This is complex technology. If one of the disks in an array using 4TB disks fails and is replaced, restoring the data (the rebuild time) may take a day or longer, depending on the load on the array and the speed of the controller. If another disk goes bad during that time, data are lost forever.

Ideal Use

  • Minimum 3 disks
  • RAID 5 is a good all-round system that combines efficient storage with excellent security and decent performance.
  • It is ideal for file and application servers that have a limited number of data drives.

RAID LEVEL 6

Provides block-level striping with parity data distributed across all disks. It requires at least 4 drives and can withstand 2 drives dying simultaneously. The chances that two drives break down at exactly the same moment are of course very small.This technique is similar to RAID 5.If a drive in a RAID 5 systems dies and is replaced by a new drive, it takes hours to rebuild the swapped drive. If another drive dies during that time, you still lose all of your data. With RAID 6, the RAID array will even survive that second failure.

Raid 6

Advantages

  • Like with RAID 5, read data transactions are very fast.
  • If two drives fail, you still have access to all data, even while the failed drives are being replaced. So RAID 6 is more secure than RAID 5.

Disadvantages

  • Write data transactions are slowed down due to the parity that has to be calculated.
  • Drive failures have an effect on throughput, although this is still acceptable.
  • This is complex technology. Rebuilding an array in which one drive failed can take a long time.

Ideal Use

  • RAID 6 is a good all-round system that combines efficient storage with excellent security and decent performance.

RAID LEVEL 10

Combining RAID 1 and RAID 0, this level is referred to as RAID 10, which offers higher performance than RAID 1 but at a much higher cost. In RAID 1+0, the data is mirrored and the mirrors are striped.This is a hybrid RAID configuration. It provides security by mirroring all data on secondary drives while using striping across each set of drives to speed up data transfers.

RAid 10

Advantages

  • If something goes wrong with one of the disks in a RAID 10 configuration, the rebuild time is very fast since all that is needed is copying all the data from the surviving mirror to a new drive. This can take as little as 30 minutes for drives of  1 TB.

Disadvantages

  • Half of the storage capacity goes to mirroring, so compared to large RAID 5  or RAID 6 arrays, this is an expensive way to have redundancy.

Ideal Use

  • Minimum 4 disks.
  • Excellent performance

RAID is no substitute for back-up!

All RAID levels except RAID 0 offer protection from a single drive failure. A RAID 6 system even survives 2 disks dying simultaneously. For complete security you do still need to back-up the data from a RAID system.

Conclusion

Based on the number of available disk drives and your requirements for performance and reliability. Disk drive usage, read performance, and write performance depend on the number of drives in the array. In general, the more drives, the better the performance.

While RAID 0 is the least costly, it could never be used for databases unless you can withstand data loss or rebuild adequately from other backed up media.

RAID 1 and 10 win on data protection, but lose in terms of disk costs. RAID 10 offers the best performance and data protection, but at a cost.

RAID 5 offers the best trade-off in terms of price and performance, and includes data protection for database use.

27Oct/15

Different Ways of File transfer to a remote server using ssh protocol

Different Ways of File transfer to a remote server using ssh protocol.

Scp allows files to be copied to, from, or between different hosts. It uses ssh for data transfer and provides the same authentication and same level of security as ssh.

Using scp from destination server

scp root@source_server:/path/to/file /path/here/
scp -P 2222 root@source_server:/path/to/file /path/here/ #with ssh port 2222
scp -r root@source_server:/path/to/directory/ /path/here/ #copy entire directory

Using scp from source server Continue reading

24Oct/15

Output alignment problem for ‘df’ command

Sometimes we need to get the output of df command in an arranged manner to use the output in some scripting or not. You can use the following command to view the output in properly formatted form.

df -Ph

   -P, --portability use the POSIX output format
   -h, --human-readable print sizes in human readable format (e.g., 1K 234M 2G)

You can check the following screenshots for more details.
Continue reading

14Sep/15

cPanel/WHM Successful logins

For getting the successful cPanel/WHM logins, using the following commands.

For getting the successful cPanel logins.

cat /usr/local/cpanel/logs/session_log | grep "myuser" | grep "NEW .*app=cpaneld"
# "myuser" is cPanel username

xx.xx.xx.xx [09/11/2015:13:17:40 -0000] NEW myuser:bOMyuserz8hKvThis1XUgnISnh4AWMMXSampleKgHE3lString1JpnOSiK5a45t3 address=122.165.84.98,app=cpaneld,creator=myuser,method=handle_form_login,path=form,possessed=0

For gettign successful WHM logins

cat /usr/local/cpanel/logs/session_log | grep "root" | grep "NEW .*app=whostmgrd"
# Use required WHM user instead of "root"

xx.xx.xx.xx [09/05/2015:07:22:39 -0000] NEW root:KGJsPXy_h243av2XchbPGBajfsSDj0eRz4ryHIj_tGZtYODFSZVb5s4rkdx20LJd address=xx.xx.xx.xx,app=whostmgrd,creator=root,method=handle_form_login,path=form,possessed=0
16Oct/14

Setup IM client for Kayako Live Chat

Here I am writing a short guide to setup IM client for Kayako live chat, as I feel the instructions in their website is little confusing. Setting up IM ( XMPP ) live chat client is very helpful for people, whom are using Linux as there is no official Live Cht client for Linux yet.

To start with the configuration, you need to install an IM client first. I use Pidgin on my system and it is one of my personl favourites.

Next you need to register your throaway yourhelpdeskname.kayako.com FQDN for your heldesk. You can do it from https://my.kayako.com/Backend/ChatDomain/ ; make sure you have a valid to login their system. Additionally inster your helpdesk URL with “https” if you have SSL installed for your helpdesk; otherwise you will not be able to add encryption support to the chat.

Once the FQDN is generated, copy it out.

Now open your IM client and add a new Account. Fill in the values as following.

Username :- Your helpdek user name
Domain :- FQDN generated from https://my.kayako.com/Backend/ChatDomain/
Password :- Your helpdesk password
Connect Server :- chatgateway.kayako.com
Connect Port :- 5222
Connection Security :- Require Encryption ( if you have https enabled ; else use “Use encryption if it is available” )

Thats it! Enable account and enjoy the live chat facility 🙂

To read more about the instructions and tips to handle chats, please have a look at https://kayako.atlassian.net/wiki/display/DOCS/Kayako+Chat+Gateway

01Sep/14

SMTP Error (535): Authentication failed in Roundcube Webmail

We were not able to send mails from Round Cube and while trying we were getting this error.

SMTP Error (535): Authentication failed

To fix this we need to make a change  in the RoundCube config file.

In a normal server , roundcube config file will be this  /usr/share/roundcube/config/main.inc.php

To fix this we need to change the below value and save the config file.

$rcmail_config[‘smtp_user’] = ‘%u’;

to

$rcmail_config[‘smtp_user’] = ”;

After this you should be able to send mails without any issues.







16Aug/14

pnp4nagios Installation and Configuration

Installation
—————-

PNP is an addon for the Nagios Network Monitoring System. PNP provides easy to use, easy to configure RRDTools based performance charts feeded by the performance data output of the Nagios Plugins. To install this,

1. Download the latest version of pnp4nagios source from http://sourceforge.net/projects/pnp4nagios/

2. Untar it and cd into the extracted directory.

3. Run ./configure –with-nagios-user=nagios –with-nagios-group=nagios

a. Some lines run across the screen after running this. The paths shown should be checked. If the displayed values aren’t correct you can change them calling ./configure with appropriate options( ./configure –help ).

NB:: Make sure that we have rrdtool and perl-rrdtool are installed on our server.

4. Run make; make install clean; make install-webconf; make install-config; make install-init;

Attention: After copying the configuration file for the web server you have to restart the web server (/etc/init.d/httpd restart).

A detailed installation documentation can be found at http://docs.pnp4nagios.org/pnp-0.6/install

Configuration
——————

We can configure pnp4nagios in three different modes, they are

Default Mode
Bulk Mode
Bulk Mode with NPCD

Among these, Default mode is less complicated and it will take less time to configure. To configure pnp4nagios in Default mode,

1. Enable processing of performance data in nagios.cfg. Please note that this directive might already exist in the config file. Default is “0�?.

process_performance_data=1

2. Data processing has to be disabled in the definition of every host or service whose performance data should NOT be processed. By default it isn’t enabled for any definitions. Just make sure that the particular directive isn’t explicitly set to 1.

define service {

process_perf_data 0

}

3. Set enable_environment_macros to 1 in nagios.cfg

4. Additionally the command to process performance data is to be specified in nagios.cfg

service_perfdata_command=service_perfdata

5. Starting with Nagios 3.0 it may be useful to enable processing of performance data for hosts as well. Due to changed host check logic Nagios 3 now performs regularly scheduled host checks.

host_perfdata_command=host_perfdata

6. Define the following two commands from nconf

check command name – service_perfdata

check command line – /usr/bin/perl /usr/local/pnp4nagios/libexec/process_perfdata.pl
check command name – host_perfdata

check command line – /usr/bin/perl /usr/local/pnp4nagios/libexec/process_perfdata.pl -d HOSTPERFDATA

7. Save the changes and run generate nagios configuration.
Read more details at http://docs.pnp4nagios.org/pnp-0.4/config

17Jul/14

Product images not working and giving “Warning: Creating default object from empty value” Error

Last day there was an issue for a wordpress installation. None of the product images are not working and if we take the image directly in the browser, we can see the below errors

==================
Warning: Creating default object from empty value in /home/wp-user/public_html/wp-content/plugins/shopp/core/model/Asset.php on line 123

Warning: Cannot modify header information – headers already sent by (output started at /home/wp-user/public_html/wp-content/plugins/shopp/core/model/Asset.php:123) in /home/wp-user/public_html/wp-content/plugins/shopp/core/model/Asset.php on line 199

Warning: Cannot modify header information – headers already sent by (output started at /home/wp-user/public_html/wp-content/plugins/shopp/core/model/Asset.php:123) in /home/wp-user/public_html/wp-content/plugins/shopp/core/model/Asset.php on line 200

Continue reading

09Jul/14

Find domains targeted for wordpress brute-force attack in Plesk

The following script will give an overview of all the domains and the corresponding hits to wordpress login page. By analyzing the result, you will be be able to find which all domains are facing brute-force attack.


for dom in `ls -l /var/www/vhosts/ | awk -F” ” {‘print $9’}`; do if [ -f /var/www/vhosts/$dom/statistics/logs/access_log ]; then COUNT=`grep wp-login.php /var/www/vhosts/$dom/statistics/logs/access_log |wc -l`; echo “$dom:$COUNT”;fi; done | sort -n -t “:” -k 2 -r
